-18℃ Air Cooling Refrigeration Condensing Unit 30 HP For Chiller

Product Details:

Place of Origin:	China
Brand Name:	Gaoxiang
Certification:	CE , ISO
Model Number:	GXN30CBFZD

Payment & Shipping Terms:

Minimum Order Quantity:	1 Pc
Price:	Negotiation
Packaging Details:	Standard Export Packing
Delivery Time:	20 ~ 30 Days
Payment Terms:	L/C , T/T
Supply Ability:	100 Pcs / Month

Contact Now

Detailed Product Description

Type:	Cold Room Condensing Unit	Structure:	Assembled
Refrigerant:	R404a	Suitable For:	Cold Room
Suction Coupling:	2 - 1 / 8 〞	Dry Filter:	ALCO
High Light:	freezer condenser unit , cold room condensing unit

30HP -18℃ Air Cooling Refrigeration Condensing Unit For Chiller

Product Features :

1 . Reliable Performance

2 . Safely Running

3 . High Efficiency And Energy Saving

4 . Quality Enhancement
5 . Widely Applied

Water - Cooled Refrigeration Condensing Unit Technical parameters :

1 . Condenser Details :

Form	Rated Air Flow ( m³/ h )	Connection Size
Fin Condenser	2*15000	RC 7 / 8 - 2 - 1 / 8

2 . Refrigerant Capacity Of Compressor :

a . Evaporating Temperature - 15 ℃

Cooling Capacity	44100 W
Power	26000 W

b. Evaporating Temperature - 25 ℃

Cooling Capacity	28600 W
Power	19900 W

c . Evaporating Temperature - 35 ℃

Cooling Capacity	16750 W
Power	14900 W

3 . Coupling

Tube Coupling	7 / 8 〞
Suction Coupling	2 - 1 / 8 〞

4 . Overall Dimensions :

Length ( L )	1900 mm
Width ( B )	1175 mm
Height ( H )	1980 mm

Standard configuration of units : compressor , condenser , liquid receiver , pressure controller , pressure gauge , filter , solenoid valve and wiring box , etc .

Note: 　

1 . Cooling capacity in the form is calculated when the ambient temperature is 40℃ .

2 . Configuration can be added according to customers' requirements .
