Hermetic Air Cooled Condensing Unit With Copeland Scroll Compressor Low Noise

Hermetic Air Cooled Condensing Unit With Copeland Scroll Compressor Low Noise

  • Hermetic Air Cooled Condensing Unit With Copeland Scroll Compressor Low Noise
  • Hermetic Air Cooled Condensing Unit With Copeland Scroll Compressor Low Noise
  • Hermetic Air Cooled Condensing Unit With Copeland Scroll Compressor Low Noise
Hermetic Air Cooled Condensing Unit With Copeland Scroll Compressor Low Noise
Product Details:
Place of Origin: China
Brand Name: Gaoxiang
Certification: CE / ISO
Model Number: GXN8CBZG
Payment & Shipping Terms:
Minimum Order Quantity: 1Pc
Price: Negotiation
Packaging Details: Standard Export Packing
Delivery Time: 20 ~ 25 Days
Payment Terms: L/C , T/T
Supply Ability: 200Pcs / Month
Contact Now
Detailed Product Description
Product Name: Air Cooled Units Expansion Valve: Danfoss
Dry Filter: ALCO Compressor: Copeland
Specification: 8HP
High Light:

cool room refrigeration units

,

copeland scroll condensing units




0 ℃ V - Type Air Cooled Hermetic Condensing Unit With Copeland Compressor


Product Instruction :

This series products feature box type structure with scroll compressor compressor , that is compact and pleasant looking , applicable to cold display cases , cold storage rooms , ice producers etc . The applicable temperature ranges are : 0ºC ~ - 10ºC and - 15 ºC ~ - 18 ºC . They can be used in hotels , restaurants , medicines , agricultural , chemicals industries all other place where cold storage is needed .



Product description:
1 . With series semi-hermetic compressor
2 . With copper tube V type air cooled condenser
3 . Air cooled condensing units with low noise and high efficient external rotor fan motor .

4 . Small space occupying, convenient for packing and transportation ;
5 . With high quality China made or imported components .
6 . Beautiful and durable appearance design , anti - collision and rain proof ;

7 . Complete models with wide temperatures using , and can be used widely for storage ,
cooling , ice-making , freezing , etc .


Piping :

All pipe system are industrial copper pipes and are made for industries . By pipes up to 11 / 8 diameter they will be bend monolithic and there is no use of welding flexion . Welding will be made by qualified workers with high quality materials for every parts where welding is required . By pipes with pipe coupling parts , we use leak proof chemicals which are especially produced for the cooling industry .





Hermetic Condensing Unit Technical parameters :



1 . Refrigerant Capacity Of Compressor :

a . Evaporating Temperature + 5 ℃

Cooling Capacity 19950 W
Power 7670 W



b. Evaporating Temperature - 5 ℃

Cooling Capacity 14650 W
Power 7060 W



c . Evaporating Temperature - 12 ℃

Cooling Capacity 11400 W
Power 6690 W



Standard configuration of units : compressor , condenser , liquid receiver , pressure controller , pressure gauge , filter , solenoid valve and wiring box , etc .



Note:

1 . Cooling capacity in the form is calculated when the ambient temperature is 32℃ .

2 . Configuration can be added according to customers requirements .





Every Unit Configuration :



Reservoir 1Pc
Solenoid Valve 1Pc
Dry Filter 1Pc
Mirror Liquid 1Pc
High and Low Pressure Controller 1Pc
High and Low Pressure Gauge 2Pcs
Copper Pipes & Insulation 1 set
Expansion Valve 1Pc
R22 Refrigerant 1 set
