Customized Semi Hermetic Condensing Unit , Cold Room Freezer Units For Hotel

Customized Semi Hermetic Condensing Unit , Cold Room Freezer Units For Hotel

  • Customized Semi Hermetic Condensing Unit , Cold Room Freezer Units For Hotel
  • Customized Semi Hermetic Condensing Unit , Cold Room Freezer Units For Hotel
  • Customized Semi Hermetic Condensing Unit , Cold Room Freezer Units For Hotel
Customized Semi Hermetic Condensing Unit , Cold Room Freezer Units For Hotel
Product Details:
Place of Origin: China
Brand Name: Gaoxiang
Certification: CE , ISO
Model Number: GXN2CBFZD
Payment & Shipping Terms:
Minimum Order Quantity: 1Pc
Price: Negotiation
Packaging Details: Standard Export Packing
Delivery Time: 20 ~ 25 Days
Payment Terms: L/C , T/T
Supply Ability: 100Pcs / Month
Contact Now
Detailed Product Description
Type: Refrigeration Equipment Refrigerant: R404a
Power Supple: 380V / 50Hz Compressor: Customized
Compressor Type: Bitzer Usage: Hotel Cold Room
High Light:

cold storage refrigeration units

,

copeland condensing unit





Customized Semi - Hermetic Air Cooled Condensing Unit For Hotel Cold Room





Semi - Hermetic Air - Cooled Refrigeration Unit Technical parameters :



1 . Condenser Details :

Qty Of Fan ( piece ) Air Volume ( m3 / h ) Power of Fan ( W )
1 1 * 800 1 * 120



2 . Refrigerant Capacity Of Compressor :

a. Evaporating Temperature-25 ℃

Cooling Capacity 2830 W
Power 2070 W



b . Evaporating Temperature - 35 ℃

Cooling Capacity 1650 W
Power 1490 W



3 . Coupling

Tube Coupling 3 / 8 〞
Suction Coupling 7 / 8 〞



4 . Overall Dimensions :

Length ( L ) 600mm
Width ( B ) 700mm
Height ( H ) 520mm



5 . Mounting Dimensions :

Length ( D ) 550mm
Width ( E ) 420mm



Standard configuration of units : compressor , condenser , liqid receiver , pressure controller , pressure gauge , filter , solenoid valve and wiring box , etc .



Note :

1 . Cooling capacity in the form iscalculated when the ambiernt temperature is 32℃.

2 . Configuration can be added according to customers' requirements .

3 . When the compressor using refrigerant R22,and evaporating temperature lower than - 15 ℃ cylinder head fan must be installed . When the evaporating temperature below - 25 ℃ the compressor hydrojet system also must be installed .

4 . When the compressor using refrigerant R404a ,and evaporating temperature lower than - 20 ℃ cylinder head fan must be installed .
