Air Cooled 0 ℃ Refrigeration Condensing Unit 5HP Copeland Compressor For Blast Freezer

Air Cooled 0 ℃ Refrigeration Condensing Unit 5HP Copeland Compressor For Blast Freezer

  • Air Cooled 0 ℃ Refrigeration Condensing Unit 5HP Copeland Compressor For Blast Freezer
  • Air Cooled 0 ℃ Refrigeration Condensing Unit 5HP Copeland Compressor For Blast Freezer
  • Air Cooled 0 ℃ Refrigeration Condensing Unit 5HP Copeland Compressor For Blast Freezer
  • Air Cooled 0 ℃ Refrigeration Condensing Unit 5HP Copeland Compressor For Blast Freezer
Air Cooled 0 ℃ Refrigeration Condensing Unit 5HP Copeland Compressor For Blast Freezer
Product Details:
Place of Origin: China
Brand Name: Gaoxiang
Certification: ISO / CE
Model Number: GXW5CQFZG
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pc
Price: Negotiation
Packaging Details: Standard Export Packing
Delivery Time: 20 ~ 30 Days
Payment Terms: L/C , T/T
Supply Ability: 100Pcs / Month
Contact Now
Detailed Product Description
Type: Air Cooled Industrial Chiller Refrigerant: R404a
Power Suppler: 380V / 50 Hz Material: Painted Galvanized Steel Shelf
Size: Small Trademark: Copeland
High Light:

freezer condenser unit

,

cold room condensing unit





5HP Air - Cooled 0 ℃ Condensing Unit Copeland Compressor For Blast Freezer





Product Features :



1 . According to customer ' s requirement , this item can be widely applied to hotels , restaurants , food medicine store , agriculture , chemical engineering and other industries . Temperature range from - 5ºC to 10ºC , and - 10ºC to 18ºC
3 . Main compressors can be matched with Copeland ,Danfoss and other freezing scroll compressor with small vibration , low noise and good working reliability ;
4 .  Condenserwith copper pipe plus aluminum sheet type for high efficiency and stabilization .
5 . Terminal box with convenient wiring ;
6 . Convenient to engimeer and repair with installation stop valves .



Air - Cooled Refrigeration Condensing Unit Technical parameters :



1 .  Condenser Details :

Qty Of Fan ( piece )

Air Volume  ( m3 / h )

Power of Fan ( W )

2 2 * 3200 2 * 60



2 . Refrigerant Capacity Of Compressor :

a . Evaporating Temperature + 5 ℃

Cooling Capacity

13050 W

Power

4260 W



b. Evaporating Temperature - 5 ℃

Cooling Capacity 9270 W
Power 3780 W



c . Evaporating Temperature - 20 ℃

Cooling Capacity 7160 W
Power 3400 W



3 . Coupling

Tube Coupling

1 / 2 〞

Suction Coupling

3 / 4 〞



4 . Overall Dimensions :

Length ( L )

980mm

Width ( B )

410mm
Height ( H ) 1330mm



Standard configuration of units : compressor , condenser , liquid receiver , pressure controller , pressure gauge , filter , solenoid valve and wiring box , etc .



Note:

1 . Cooling capacity in the form is calculated when the ambient temperature is 32℃ .

2 . Configuration can be added according to customers requirements .
