8HP Low Temp Water Cooled Box Type V Condensing Unit For Sea Food Freezer
Product Features :
1 . Application range : food processing , logistic center , vegetable preservation , meat processing center , chain restaurant,medicine stores , seeds processing store,medical lab , biological medicine store , dairy products processing , edible fungus breeding center , Temperature range from - 5 ºC to - 23 ºC
2 . Box type refrigerating unit is composed of refrigeration compressor with high performance , condenser with optimized design and control element .
3 . The entire design is reasonable . Upward design of air outlet of condenser reduces the interference to surrounding environment and meets the concept of environmental protection .
Hermetic Water - Cooled Refrigeration Unit Technical Parameters :
1 . Condenser Details :
Condenser Form : Shell & Tube Condenser
Rated Water Flow ( m3 / h ) : 3
Connection Size : RC 1 - 1 / 2
2 . Refrigerant Capacity Of Compressor :
a . Evaporating Temperature - 15 ℃
Cooling Capacity : 16050 W
Power : 6870 W
b. Evaporating Temperature - 25 ℃
Cooling Capacity : 10250 W
Power : 6120 W
c . Evaporating Temperature - 35 ℃
Cooling Capacity : 4440 W
Power : 3680 W
3 . Coupling
| Tube Coupling |
5 / 8 〞 |
| Suction Coupling |
1 - 3 / 8 〞 |
4 . Overall Dimensions :
| Length ( L ) |
1162mm |
| Width ( B ) |
300mm |
| Height ( H ) |
704mm |
5 . Mounting Dimensions :
Length ( D ) : 600mm
Width ( E ) : 200mm
Standard configuration of units : compressor , scroll and tube condenser , pressure controller , pressure gauge , filter , solenoid valve and wiring box , etc .
Note:
1 . Cooling capacity in the form is calculated when the ambient temperature is 40℃ .
2 . Configuration can be added according to customers requirements .
Overall Dimension Diagram Of Water - Cooled Refrigeration Unit :
