|Place of Origin:||China|
|Certification:||CE , ISO|
|Minimum Order Quantity:||1Pcs|
|Packaging Details:||Standard Export Packing|
|Delivery Time:||20 ~ 25 days|
|Supply Ability:||100 Pcs / Month .|
|Products Name:||Cooling System||Compressor:||Semi - Hermetic|
|Cooling Type:||Air Cooled||Control Leads & Parts:||Qiguang|
|Electric Controler:||Elitech||Delivery Time:||15 Days After Receiving Deposit|
walk in cooler refrigeration unit,
30HP Air - Cooled Semi Hermetic Condensing Unit Medium And High Temperature
Product Feature :
♦ Air cooling and high efficient evaporators are manufactured in two ways .
♦ Heat transfer surface which is placed on inflated copper tube bundles has and aluminum wavy wings form .
♦ Evaporator fans have European origin with high efficiency axial fan and have an IP55 electrical protection box .
♦ Resistant sticks of high quality are used for defrosting . As we are aiming at getting the maximum efficiency , we have put the resistant sticks in copper tubes .
♦ Connector ends of fan and resistant electricity are connected with terminals in plastic box with IP55 protection.
♦ It exists a system of By - Pass tray the drain hose for easily emptying the water of defrost
♦ Evaporator has additionally a tray resistant and drain hose tail resistant . Thermostatic expansion valve is mounted on the inlet of the evaporator and here by it will be forwarded .
♦ Evaporator RAL 9010 in ( White ) electoral powder colored is cased in galvanized steel sheet .
Product description :
1 . With series semi - hermetic compressor
2 . With copper tube V type air cooled condenser
3 . Air cooled condensing units with low noise and high efficient external rotor fan motor .
4 . Small space occupying, convenient for packing and transportation ;
5 . With high quality China made or imported components .
6 . Beautiful and durable appearance design , anti - collision and rain proof ;
7 . Complete models with wide temperatures using , and can be used widely for storage ,
cooling , ice - making , freezing , etc .
Water - Cooled Condensing Unit Technical Parameters :
1 . Refrigerant Capacity Of Compressor :
a . Evaporating Temperature - 15 ℃
Cooling Capacity : 16050 W
Power : 6870 W
b. Evaporating Temperature - 25 ℃
Cooling Capacity : 10250 W
Power : 6120 W
c . Evaporating Temperature - 35 ℃
Cooling Capacity : 4440 W
Power : 3680 W
2 . Coupling
Tube Coupling : 5 / 8 〞
Suction Coupling : 1 - 3 / 8 〞
