Place of Origin: | China |
Brand Name: | Gaoxiang |
Certification: | CE , ISO |
Model Number: | GXB125HBZG2 |
Minimum Order Quantity: | 1 Pc |
---|---|
Price: | Negotiation |
Packaging Details: | Standard Export Packing |
Delivery Time: | 20 ~ 30 Days |
Payment Terms: | L/C , T/T |
Supply Ability: | 10 Pcs / Month |
Product Name: | Refrigerator Condenser | Refrigerant: | R22 |
---|---|---|---|
Payment: | 30 %TT Deposit , 70 % Against The B / L Copy | Expansion Valve: | Danfoss |
Warranty: | 1 Year | Structural Form: | Vertical |
High Light: | refrigeration screw compressor,screw compressor refrigeration system |
125HP Copeland Screw Compressor Unit For Tunnel Freezer
Product Feature :
1 . Excellent energy efficiency : high - efficiency refrigerant and high - performance compressors .
2 . Uses an environmentally friendly , non - ozone - depleting refrigerant .
3 . Very low sound level , zero vibrations .
4 . Easy installation: compact dimensions .
5 . Quick installation: delivered ready to run .
6 . Easy maintenance: easily-detachable panels provide access to all internal components,
Screw Compressor Unit Technical parameters :
Model of unit | GXB125HBZG2 | ||
Applicable Temp. | + 10 ~ - 15 ℃ | ||
Refrigerant | R22 | ||
Power supply | 380V 50Hz | ||
Condenser | Form | Shell and Tube Condensor | |
Rated water flow | 88 | ||
Connection Size | 5‘’ | ||
Cooling capacity & Power | Evaporating Temperature 0 ℃ | Cooling Capacity | 371.5 |
Power | 101 | ||
Evaporating Temperature - 5 ℃ | Cooling Capacity | 307.4 | |
Power | 96.8 | ||
Evaporating Temperature - 10 ℃ | Cooling Capacity | 252.5 | |
Power | 92.7 | ||
Cupling | Discharge Cupling | 108 | |
Suction Coupling | 42 | ||
Discharge Cupling | 108 | ||
Suction Coupling | 42 | ||
Overall Dimensions | Length ( A ) mm | 2850 | |
Width ( B ) mm | 850 | ||
Height ( C ) mm | 1300 |
Description :
Refrigeration equipment exclusively used in cold room , widely use in hotel , foodstuff , health , medicine , agriculture , chemical industry and so on .
Temperature arrangement :
High Temperature ( - 5 ℃ ~ + 5 ℃ )
Medium Temperature ( - 18 ℃ ~ - 20 ℃ )
Low Temperature( - 25 ℃ ~ - 30 ℃ )
Blast Freezer ( -25 ℃ ~ - 40 ℃ )
