100mm Color Steel Cold Room Insulation Panels For Food Processing Room

100mm Color Steel Cold Room Insulation Panels For Food Processing Room

  • 100mm Color Steel Cold Room Insulation Panels For Food Processing Room
  • 100mm Color Steel Cold Room Insulation Panels For Food Processing Room
  • 100mm Color Steel Cold Room Insulation Panels For Food Processing Room
100mm Color Steel Cold Room Insulation Panels For Food Processing Room
Product Details:
Place of Origin: China
Brand Name: Xin Xing Yuan
Certification: CE / ISO
Model Number: 100mm
Payment & Shipping Terms:
Minimum Order Quantity: 1 ㎡
Price: Negotiation
Packaging Details: Standard Export Packing
Delivery Time: 15 Work Days
Payment Terms: L/C , T/T
Supply Ability: 12000 ㎡ / Month
Contact Now
Detailed Product Description
Product Name: Sandwich Panel Purpose: Hotel Cold Storage
Application Temperature: Temperature - 15°C Or Above Density: 38 ~ 42 Kg / M³
Structure: 3 Layers Material: PU , Color Steel
High Light:

cold room sandwich panel

,

polyurethane insulation panels





100mm Color Steel Cold Storage Insulation Panel For Food Processing Room





Product Features :

  1. Light weight
  2. Superior thermal resistance behavior
  3. B1 Level Fire - resistance
  4. Waterproof , moisture - prof
  5. High bearing capacity





Products Application :



Our products can be apply to either in cold storage ( chiller / freezer ) , ware house , clean rooms , portable room , production room , food processing room , controlled atmosphere room , pharmaceutical storage , ect .





Products Instruction :



Insulated cold storage panel system offers low operating costs , thanks to high levels of both thermal insulation properties and air tightness . Panel thicknesses from 50mm to 200mm and different coating options for higher levels of hygiene makes this panel system suitable for different types of cold storage .



Our cold storage panels have high quality PIR insulation material to ensure long term durability , even in the most demanding applications .


For more detailed information, please contact Our technical support .





Thickness of sandwich panel Application temperature
50mm Temperature 5°C or above
75mm Temperature - 5°C or above
100mm Temperature - 15°C or above
120mm Temperature - 25°C or above
150mm Temperature - 35°C or above
200mm Temperature -4 5°C or above
