Color Steel Cold Room Insulation Panels 42 Kg / M³ PU Lock Panel For Workshop

China Color Steel Cold Room Insulation Panels 42 Kg / M³  PU Lock Panel For Workshop supplier
Color Steel Cold Room Insulation Panels 42 Kg / M³  PU Lock Panel For Workshop supplier Color Steel Cold Room Insulation Panels 42 Kg / M³  PU Lock Panel For Workshop supplier Color Steel Cold Room Insulation Panels 42 Kg / M³  PU Lock Panel For Workshop supplier

Large Image :  Color Steel Cold Room Insulation Panels 42 Kg / M³ PU Lock Panel For Workshop

Product Details:

Place of Origin: China
Brand Name: Xin Xing Yuan
Certification: CE / ISO
Model Number: 100mm

Payment & Shipping Terms:

Minimum Order Quantity: 1 ㎡
Price: Negotiation
Packaging Details: Standard Export Packing
Delivery Time: 15 Work Days
Payment Terms: L/C , T/T
Supply Ability: 12000 ㎡ / Month
Contact Now
Detailed Product Description
Product Name: Cold Storage Panels Purpose: Hotel Cold Storage
HS Code: 7308900000 Density: 38 ~ 42 Kg / M³
Structure: 3 Layers Material: PU , Color Steel

100mm 42 Kg / m³ Cold Storage Insulation Panel Color Steel PU Lock Panel





What is PU Sandwich Panel ?



Composed of 2 layers PPGI steel sheet , or aluminum sheet , and core polyurethane foam insulation material .
Sandwich Panel System is suitable for the various roofs and walls referring to the large size factory buildings , workshop , warehouse , exhibition halls , gymnasiums , freezing stores , etc .





Muti - Choices :



According to different usage of insulated panels , PU Sandwich Panel can be divided into three types : Wall panel , Roof panel , Cold Store Sandwich Panel . Widely used in industrial and commercial buildings , Cold Storages , Clean Rooms , warehouses and prefab buildings





Super Insulation :



Low thermal conductivity of PU sandwich panels with excellent thermal insulation properties , can greatly reduce the thickness of periphery of the building structure , which effectively increasing the interior area of the building and save energy and costs .





Super Flame Retardation :



The coefficient of thermal conductivity is 0.023w / ( m • k ) , which ensures better thermal insulation efficiency . In practice , this effectively keeps the building absorbing heat and brings enormous economic benefits .





Products Specification :



Density 40 - 45kg / m³
The thermal conductivity 0.019 - 0.023W / M . K
Moisture permeability coefficient ≤ 3.34Ng / Pa / m . s
Water absorption ≤ 0.5g / 100 cm²
Enclosed rate ≥ 97 %
The compression strength ≥ 220 KPa
The bending strength ≥ 2450KN / m²
Oxygen index ≥ 28
Fire proof B1
Dimensional stability ≤ 1 %
Application temperature - 50 ℃ - 150 ℃
Exterior Steel thickness 0.4 - 0.7mm
Interior steel thickness 0.4 - 0.7mm
Core material thickness 40 / 50 / 60 / 75 / 100 / 120 / 150 / 200mm
Length Less than 11.8m
Effective width Wall panel : 400 - 1120mm ; Roof panel : 1000mm
Grace finish Embosser , small wave , big rib , flat finish
Advantage Heat Insulation , light weight , quick installation , waterproof , fireproof , soundproof , energy - saving , environmental friendly
Usage Various roofs and walls referring to the large size factory building , workshop , cold storage , villas
